SDJCR-External Turning
SDJCR-External Turning - Image 2

SDJCR-External Turning

SDJCR- KLEMMDREHHALTER

Code DC.. R L H1 H B F L1 L2 λS Ƴ0 Insert Shim Screw Screw Torx
HEI.1028600 ● ● 8 8 10 100 16 0 0 DC.T 0702.. – – M2,5X7 T08
HEI.1028700 ● ● 10 10 12 100 16 0 0 DC.T 0702.. – – M2,5X7 T08
HEI.1028800 ● ● 12 12 16 100 20 0 0 DC.T 0702.. – – M2,5X7 T08
HEI.1028900 ● ● 16 16 20 100 25 0 0 DC.T 0702.. – – M2,5X7 T08
HEI.1029000 ● ● 16 16 20 100 25 0 0 DC.T 11T3.. DC..011 M5X0.5XM3.5 M3,5X14 T15
HEI.1029100 ● ● 20 20 25 125 35 0 0 DC.T 11T3.. DC..011 M5X0.5XM3.5 M3,5X14 T15
HEI.1029200 ● ● 25 25 32 150 40 0 0 DC.T 11T3.. DC..011 M5X0.5XM3.5 M3,5X14 T15
HEI.1029300 ● ● 32 32 40 170 40 0 0 DC.T 11T3.. DC..011 M5X0.5XM3.5 M3,5X14 T15
