HSK-A Shell Mill Holder DIN 6357 for Milling with Driving Slot & Coolant

ISO 12164-1 (DIN 69893-1) HSK FORM A

QUERNUT-AUFSTECKFRÄSDORN DIN 6357 MIT VERGRÖSSERTEM

BUNDDURCHMESSER MIT KÜHLMITTEL

Item Code Product name Capacity D I L A
HEI.A50.0316.50 HSK 50 16 - 50 16 38 17 24 50
HEI.A50.0322.60 HSK 50 22 - 60 22 48 19 34 60
HEI.A50.0327.60 HSK 50 27 - 60 27 58 21 34 60
HEI.A50.0332.60 HSK 50 32 - 60 32 78 24 34 60
HEI.A63.0316.50 HSK 63 16 - 50 16 38 17 24 50
HEI.A63.0316.100 HSK 63 16 - 100 16 38 17 74 100
HEI.A63.0316.130 HSK 63 16 - 130 16 38 17 104 130
HEI.A63.0316.160 HSK 63 16 - 160 16 38 17 134 160
HEI.A63.0322.50 HSK 63 22 - 50 22 48 19 24 50
HEI.A63.0322.100 HSK 63 22 - 100 22 48 19 74 100
HEI.A63.0322.130 HSK 63 22 - 130 22 48 19 104 130
HEI.A63.0322.160 HSK 63 22 - 160 22 48 19 134 160
HEI.A63.0327.60 HSK 63 27 - 60 27 58 21 34 60
HEI.A63.0327.100 HSK 63 27 - 100 27 58 21 74 100
HEI.A63.0327.130 HSK 63 27 - 130 27 58 21 104 130
HEI.A63.0327.160 HSK 63 27 - 160 27 58 21 134 160
HEI.A63.0332.60 HSK 63 32 - 60 32 78 24 34 60
HEI.A63.0332.100 HSK 63 32 - 100 32 78 24 74 100
HEI.A63.0332.130 HSK 63 32 - 130 32 78 24 104 130
HEI.A63.0332.160 HSK 63 32 - 160 32 78 24 134 160
HEI.A63.0340.60 HSK 63 40 - 60 40 88 27 34 60
HEI.A63.0340.100 HSK 63 40 - 100 40 88 27 74 100
HEI.A63.0340.160 HSK 63 40 - 160 40 88 27 134 160
HEI.A100.0316.50 HSK 100 16 - 50 16 38 17 21 50
HEI.A100.0316.100 HSK 100 16 - 100 16 38 17 71 100
HEI.A100.0316.130 HSK 100 16 - 130 16 38 17 101 130
HEI.A100.0316.160 HSK 100 16 - 160 16 38 17 131 160
HEI.A100.0316.200 HSK 100 16 - 200 16 38 17 171 200
HEI.A100.0322.50 HSK 100 22 - 50 22 48 19 21 50
HEI.A100.0322.100 HSK 100 22 - 100 22 48 19 71 100
HEI.A100.0322.130 HSK 100 22 - 130 22 48 19 101 130
HEI.A100.0322.160 HSK 100 22 - 160 22 48 19 131 160
HEI.A100.0322.200 HSK 100 22 - 200 22 48 19 171 200
HEI.A100.0327.50 HSK 100 27 - 50 27 58 21 21 50
HEI.A100.0327.100 HSK 100 27 - 100 27 58 21 71 100
HEI.A100.0327.130 HSK 100 27 - 130 27 58 21 101 130
HEI.A100.0327.160 HSK 100 27 - 160 27 58 21 131 160
HEI.A100.0327.200 HSK 100 27 - 160 27 58 21 171 200
HEI.A100.0332.50 HSK 100 32 - 50 32 78 24 21 50
HEI.A100.0332.100 HSK 100 32 - 100 32 78 24 71 100
HEI.A100.0332.130 HSK 100 32 - 130 32 78 24 101 130
HEI.A100.0332.160 HSK 100 32 - 160 32 78 24 131 160
HEI.A100.0332.200 HSK 100 32 - 160 32 78 24 171 200
HEI.A100.0340.60 HSK 100 40 - 60 40 88 27 31 60
HEI.A100.0340.100 HSK 100 40 - 100 40 88 27 71 100
HEI.A100.0340.130 HSK 100 40 - 130 40 88 27 101 130
HEI.A100.0340.160 HSK 100 40 - 160 40 88 27 131 160
HEI.A100.0350.70 HSK 100 50 - 70 50 128 40 41 70
HEI.A100.0350.100 HSK 100 50 - 100 50 128 40 71 100
HEI.A100.0360.70 HSK 100 60 - 70 60 128 40 41 70
