| DC | dA | d1 | h | ap/HF | z | Item Code | Order No | Availability | Spare Parts | |
| 63 | 27 | 60 | 50 | 3,5 | 4 | HMF90 SD18.063 Z04-DA27 | 2242300 | ○ | Spann- schraube Fastening screw HK02-71271 5001600 MA = 6Nm | Torx- Schlüssel Torque wrench T25 5000500 |
| 80 | 27 | 60 | 50 | 3,5 | 5 | HMF90 SD18.080 Z05 | 2242400 | ● | ||
| 100 | 32 | 78 | 50 | 3,5 | 6 | HMF90 SD18.100 Z06 | 2242500 | ● | ||
| 125 | 40 | 90 | 60 | 3,5 | 7 | HMF90 SD18.125 Z07 | 2242600 | ● | ||
| 160 | 40 | 115 | 60 | 3,5 | 9 | HMF90 SD18.160 Z09-NC | 2242700 | ● | ||
| 200 | 60 | 140 | 65 | 3,5 | 11 | HMF90 SD18.200 Z11-NC | 2242800 | ● | ||
