| Dc | d3 | dA | d1 | h | ap | z | Item Code | Order No | Availability | Spare Parts | |
| 2.0 | 2.3 | 0.75 | 1.75 | 1.75 | 0.157 | 5 | HMFU45 XE04.2000 Z05-INCH | 2249500 | ○ | Spann- schraube Fastening screw HKE02- 51165 5002400 MA = 3Nm | Torx- Schlüssel Torque wrench IP15 5001100 |
| 2.5 | 2.8 | 1.00 | 2.00 | 1.75 | 0.157 | 5 | HMFU45 XE04.2500 Z05-INCH | 2249600 | ○ | ||
| 2.5 | 2.8 | 1.00 | 2.00 | 1.75 | 0.157 | 6 | HMFU45 XE04.2500 Z06-INCH | 2249700 | ○ | ||
| 3.0 | 3.3 | 1.25 | 2.75 | 2.00 | 0.157 | 6 | HMFU45 XE04.3000 Z06-INCH | 2249800 | ○ | ||
| 3.0 | 3.3 | 1.25 | 2.75 | 2.00 | 0.157 | 8 | HMFU45 XE04.3000 Z08-INCH | 2249900 | ○ | ||
| 4.0 | 4.3 | 1.50 | 3.50 | 2.00 | 0.157 | 8 | HMFU45 XE04.4000 Z08-INCH | 2250000 | ○ | ||
| 4.0 | 4.3 | 1.50 | 3.50 | 2.00 | 0.157 | 10 | HMFU45 XE04.4000 Z10-INCH | 2250100 | ○ | ||
| 5.0 | 5.3 | 1.50 | 3.75 | 2.50 | 0.157 | 10 | HMFU45 XE04.5000 Z10-INCH | 2250200 | ○ | ||
| 5.0 | 5.3 | 1.50 | 3.75 | 2.50 | 0.157 | 12 | HMFU45 XE04.5000 Z12-INCH | 2250300 | ○ | ||
| 6.0 | 6.3 | 2.00 | 5.00 | 2.50 | 0.157 | 10 | HMFU45 XE04.6000 Z10-NCINCH | 2250400 | ○ | ||
| 6.0 | 6.3 | 2.00 | 5.00 | 2.50 | 0.157 | 14 | HMFU45 XE04.6000 Z14-NCINCH | 2250500 | ○ | ||
| 8.0 | 8.3 | 2.50 | 6.00 | 2.50 | 0.157 | 16 | HMFU45 XE04.8000 Z16-NCINCH | 2250600 | ○ | ||
