DC | d3 | dA | d1 | h | ap | z | Item Code | Order No | Availability | Spare Parts | |
2.0 | 2.4 | 0.75 | 2.00 | 2.00 | 0.197 | 4 | HMFU45 ON08.2000 Z04-INCH | 2247100 | ○ | Spann- schraube Fastening screw HK02- 71271 5001600 MA = 6Nm | Torx- Schlüssel Torque wrench T25 5000500 |
2.5 | 2.9 | 1.00 | 2.25 | 2.00 | 0.197 | 5 | HMFU45 ON08.2500 Z05-INCH | 2247200 | ○ | ||
3.0 | 3.4 | 1.25 | 2.75 | 2.00 | 0.197 | 6 | HMFU45 ON08.3000 Z06-INCH | 2247300 | ○ | ||
3.0 | 3.4 | 1.25 | 2.75 | 2.00 | 0.197 | 7 | HMFU45 ON08.3000 Z07-INCH | 2247400 | ○ | ||
4.0 | 4.4 | 1.50 | 3.75 | 2.25 | 0.197 | 7 | HMFU45 ON08.4000 Z07-INCH | 2247500 | ○ | ||
4.0 | 4.4 | 1.50 | 3.75 | 2.25 | 0.197 | 9 | HMFU45 ON08.4000 Z09-INCH | 2247600 | ○ | ||
5.0 | 5.4 | 1.50 | 3.75 | 2.50 | 0.197 | 9 | HMFU45 ON08.5000 Z09-INCH | 2247700 | ○ | ||
5.0 | 5.4 | 1.50 | 3.75 | 2.50 | 0.197 | 11 | HMFU45 ON08.5000 Z11-INCH | 2247800 | ○ | ||
6.0 | 6.4 | 2.00 | 5.00 | 2.00 | 0.197 | 11 | HMFU45 ON08.6000 Z11-INCH | 2247900 | ○ |
