Name: DRILL SP.. 2D - U-DRILLS INDEXABLE
SKU: 2009
Availability: InStock

DRILL SP.. 2D – U-DRILLS INDEXABLE

Description

TGTC / PLBT / ZCC / KLP

DRILL SP.. 2D – U-DRILLS INDEXABLE

TGTC / PLBT / ZCC / KLP	Stock	Inter Coolant	D	d	d1	L	L1	L2	Insert	Screw	Torx Key
1220700	●	●	13	20	25	94	26	50	SP..050204	M2X5	T06
1220800	●	●	14	20	25	97	28	50
1220900	●	●	15	20	25	100	30	50
1221000	●	●	16	25	34	110	32	50	SP..060204	M2.2X5
1221100	●	●	17	25	34	112	34	56
1221200	●	●	18	25	34	114	36	56
1221300	●	●	19	25	34	116	38	56
1221400	●	●	19.5	25	34	119	40	56
1221500	●	●	20	25	34	119	40	56
1221600	●	●	20.5	25	34	122	42	56
1221700	●	●	21	25	34	122	42	56
1221800	●	●	22	25	34	125	44	56	SP..07T308	M2.5X7	T08
1221900	●	●	23	25	34	128	46	56
1222000	●	●	24	25	34	129	48	56
1222100	●	●	25	25	34	131	50	56
1222200	●	●	26	25	34	134	52	56
1222300	●	●	27	25	34	137	54	56
1222400	●	●	27.5	25	34	140	56	56	SP..090408	M3,5X8	T15
1222500	●	●	28	25	34	140	56	56
1222600	●	●	29	25	34	143	58	56
1222700	●	●	30	32	44	150	60	60
1222800	●	●	31	32	44	153	62	60
1222900	●	●	32	32	44	156	64	60
1223000	●	●	33	32	44	159	66	60
1223100	●	●	34	32	44	162	68	60	SP..110408	M4X11
1223200	●	●	35	32	44	165	70	60
1223300	●	●	36	32	44	168	72	60
1223400	●	●	37	32	44	171	74	60
1223500	●	●	38	32	44	174	76	60
1223600	●	●	39	32	44	177	78	60
1223700	●	●	40	32	44	180	80	60
1223800	●	●	41	32	44	183	82	60
1223900	●	●	42	32	44	186	84	60	SP..140512	M5X11	T20
1224000	●	●	42.5	32	44	189	86	60
1224100	●	●	43	32	44	189	86	60
1224200	●	●	44	32	44	192	88	60
1224300	●	●	45	40	54	195	90	70
1224400	●	●	46	40	54	198	92	70
1224500	●	●	47	40	54	201	94	70
1224600	●	●	48	40	54	204	96	70
1224700	●	●	49	40	54	207	98	70
1224800	●	●	50	40	54	210	100	70

DRILL SP.. 2D – U-DRILLS INDEXABLE
