Product Table
| ISO CCMT 06/09 | Stock | D | Z | a | L | L1 | L2 | d1 | Insert | Screw | Torx Key |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1140100 | ● | 17 | 2 | 8 | 85 | 8 | 20 | 16 | CC..0602 | M2,5x7 | T08 |
| 1140200 | ● | 20 | 2 | 9 | 85 | 10 | 20 | 16 | |||
| 1140300 | ● | 21 | 2 | 9 | 85 | 10 | 20 | 16 | |||
| 1140400 | ● | 24 | 2 | 10 | 100 | 12 | 25 | 20 | |||
| 1140500 | ● | 25 | 2 | 11 | 100 | 12 | 25 | 25 | |||
| 1140600 | ● | 25 | 4 | 12 | 100 | 12 | 25 | 25 | |||
| 1140700 | ● | 32 | 4 | 8 | 100 | 16 | 25 | 25 | |||
| 1140800 | ● | 32 | 4 | 10 | 100 | 16 | 30 | 25 | |||
| 1140900 | ● | 63 | 8 | 8 | 125 | 31 | 40 | 32 | |||
| 1141000 | ● | 30 | 2 | 12 | 100 | 16 | 30 | 25 | CC..09T3 | M3,5x8 | T15 |
| 1141100 | ● | 32 | 2 | 14 | 100 | 16 | 30 | 25 | |||
| 1141200 | ● | 40 | 4 | 16 | 120 | 18 | 30 | 32 | |||
| 1141300 | ● | 40 | 4 | 18 | 120 | 18 | 30 | 32 | |||
| 1141400 | ● | 32 | 2 | 12 | 100 | 16 | 30 | 25 | |||
| 1141500 | ● | 40 | 4 | 12 | 120 | 18 | 30 | 32 | M3,5x9 | ||
| 1141600 | ● | 50 | 4 | 12 | 120 | 18 | 30 | 32 | |||
| 1141700 | ● | 50 | 4 | 16 | 120 | 18 | 30 | 32 |
